► H.265AI Video compression technology,high image quality, low bit rate;
► 2MP 1080P(1920X1080P) HD Resolution;
► Infrared distance: 8 high-power LED lights 35m;
► Support Max 128G TF Card, and Cloud Storage;
► Support D-WDR, 3D DNR;
► Support mobile phone remote monitoring (iOS, Android);
► Multi-browser access (IE,Chrome,Firefox,Safari);
► Support information overlay (such as ID, IP, DDNS information, etc.);
► Supporting WEB, CMS, VMS, MYEYE, cloud services;
► Supports interfacing with HVR/NVR and supports the standard Onvif protocol.

Camera	Sensor	2 MP 1/3.2" low illumination CMOS sensor
	low illumination	Color：0.01Lux @(F1.2,AGC ON); 0 Lux with IR
	low illumination	B/W：0.001 Lux @ (F1.2,AGC ON),0 Lux with IR
	Shutter	1/50(1/60)s to1/10,000s
	Lens	HD dedicated lens 3.6mm@F2.0
	Lens Mount	M12
	Day & Night	Support IR-CUT
Image	Image Size	1920*1080
	fps	PAL: 1080P@25fp
	fps	NTSC: 1080P@30fps
	Image settings	Saturation, brightness, contrast adjustable through the client or browser
Compression	standard	H.264X/H265AI Video coding compression
	Output bit rate	0.1Mbps~4Mbps
	Audio Standard	G711a
Network features	Storage	cloud storage
	Intelligent alarm	Motion detection, video loss, network cable break, IP address conflict
	Protocol	Wi-Fi wireless transmission (supports IEEE802.11b/g wireless protocol)
	General	Anti-flicker, dual stream, heartbeat, password protection
	Audio I/0	Build in Mic
General	Operating temperature	-10℃-＋60℃
	Working humidity	10%-90% RH
	Power	DC5V±10%
	IR Distance	8 high-power LED lights 30m~35m;
	Power Consumption	MAX 3W
	Protect Level	IP64
	Net Weight	Around 310g
	Size
